Hack Posted July 27 Share Posted July 27 (edited) Hi everyone, Please help me to know how to connect my volumetric motion detector (Pyronix XD10TT-AM) to my ELKRON MEDEA32 board. The detector includes pre-installed resistors to be activated by a connection as needed (see the shared assembly). Schema of the assembly of my Pyronix XD10TT-AM In my MEDEA32 board, i have 6 N/C inputs. Manual of MEDEA32 (page 24 and 25) I have also a wired add-on Elkron EP708 expansion with 8 points PGM input/output (PrIO). Manual of EP708 1) According to the assembly diagram, should I use programmed input (PGM) or the simple N/C input can be used ? 2) Which point on my MEDEA32 board that corresponds to the input (COM) on the assembly of my pyronix. Some board have zone with a groupe of "AT input / EOL and COM". But this is not the case in my MEDEA32 or the EP708 add-on. Here is an exemple of PCX46 (Pyronix) Thanks a lot Edited July 27 by Hack orthograph Quote Link to comment Share on other sites More sharing options...
al-yeti Posted July 27 Share Posted July 27 20 minutes ago, Hack said: Hi everyone, Please help me to know how to connect my volumetric motion detector (Pyronix XD10TT-AM) to my ELKRON MEDEA32 board. The detector includes pre-installed resistors to be activated by a connection as needed (see the shared assembly). Schema of the assembly of my Pyronix XD10TT-AM In my MEDEA32 board, i have 6 N/C inputs. Manual of MEDEA32 (page 24 and 25) I have also a wired add-on Elkron EP708 expansion with 8 points PGM input/output (PrIO). Manual of EP708 1) According to the assembly diagram, should I use programmed input (PGM) or the simple N/C input can be used ? 2) Which point on my MEDEA32 board that corresponds to the input (COM) on the assembly of my pyronix. Some board have zone with a groupe of "AT input / EOL and COM". But this is not the case in my MEDEA32 or the EP708 add-on. Here is an exemple of PCX46 (Pyronix) Thanks a lot So your just using the AA and TT terminals in that case without eol and without any resistors Quote Link to comment Share on other sites More sharing options...
Hack Posted July 27 Author Share Posted July 27 (edited) 1 hour ago, al-yeti said: So your just using the AA and TT terminals in that case without eol and without any resistors thaks al-yeti I understand that without resistor is functionnal like you said. But the constructor recommand the use of two transistor to avoid false alarms and short circuits. I just need to know the equivalent of (COM) in my MEDEA32 board or the add-on EP708. Edited July 27 by Hack Quote Link to comment Share on other sites More sharing options...
al-yeti Posted July 27 Share Posted July 27 28 minutes ago, Hack said: thaks al-yeti I understand that without resistor is functionnal like you said. But the constructor recommand the use of two transistor to avoid false alarms and short circuits. I just need to know the equivalent of (COM) in my MEDEA32 board or the add-on EP708. Lol I tried to look at manual it's as bad as other manuals Quote Link to comment Share on other sites More sharing options...
MrHappy Posted July 27 Share Posted July 27 Just now, al-yeti said: I tried to look at manual it's as bad as other manuals some odd ball euro thing - https://www.elkron.it/prodotti/scheda-elettronica-medea-32/?lang=en Quote Mr Veritas God Link to comment Share on other sites More sharing options...
Hack Posted July 28 Author Share Posted July 28 (edited) To have a look on the Pyronix XD10TT-AM assembly https://www.atexshop.com/download/pdf/XD10TTAM 10m External Detector.pdf Edited July 28 by Hack Quote Link to comment Share on other sites More sharing options...
al-yeti Posted July 28 Share Posted July 28 1 hour ago, Hack said: To have a look on the Pyronix XD10TT-AM assembly https://www.atexshop.com/download/pdf/XD10TTAM 10m External Detector.pdf This is easy bit lol Quote Link to comment Share on other sites More sharing options...
Hack Posted August 2 Author Share Posted August 2 Thanks a lot Al yeti I can't use the pre installed resistors in my Pyronix XD10TT because my board ELKRON recommand others (5,11-10 and 15kOhm) Then, i must install them manually like this Quote Link to comment Share on other sites More sharing options...
al-yeti Posted August 2 Share Posted August 2 1 hour ago, Hack said: Thanks a lot Al yeti I can't use the pre installed resistors in my Pyronix XD10TT because my board ELKRON recommand others (5,11-10 and 15kOhm) Then, i must install them manually like this Ok but you don't have to use the fault Quote Link to comment Share on other sites More sharing options...
